- DESCRIPTION
- CHARACTERISTICS
You don’t need a large, complicated mixer to achieve pro-quality live sound, and you don’t need to compromise on power for a simple design that’s easy for anyone to use. With the QSC TouchMix series of digital live sound mixers, you’ve got serious connectivity, routing, and effects processing in an intuitive design. QSC’s TouchMix is versatile enough to manage a wide range of medium- and small-format mixing tasks, while its touchscreen interface and built-in user help make it easy for almost anyone to use. If your goal is to have outstanding sound quality and extensive mix capabilities in the smallest form factor possible, you’ll be impressed with the QSC TouchMix series.
Its 22 mixing channels (16 Mic/Line, 4 Line, Stereo USB) and 12 outputs offer ample signal management flexibility while advanced features such as class-A microphone preamps, Anti-Feedback and Room Tuning Wizards, real-time analyzer (RTA) and 20-channel direct-to-external-drive recording make it equally competent as both a professional live sound or recording tool.
The touch-and-turn interface of TouchMix allows for tactile control over fader and mixer parameters while also providing a hardware connection to the mixer. Mixer functions and displays are duplicated via iOS® or Android® devices over Wi-Fi, providing both portable, wireless connectivity as well as additional control of mixer functionality.
The TouchMix-16 comes complete with USB Wi-Fi adapter and carrying case.
Key features include:
*Stated features require Firmware Version 3.0 or greater
- Capacitive touchscreen offers a wealth of on-screen information while also providing confident hands-on control
- 120 presets provide real-world live sound settings for commonly-used instruments and microphones (see Presets Listing under Resources / Support)
- Simple and Advanced modes offer either basic or comprehensive controls
- Anti-Feedback and Room Tuning Wizards simplify complex equalization tasks
- Real-time analyzer (RTA) provides instantaneous display of channel tonal balance and room response
- 10 Aux mixes provide superior monitor configuration capabilities
- 22-channel direct-to-hard drive record/playback — capture and recall performances without the need for an external computer
- MP3 playback direct from USB
- On-board multi-language user guide
- Download future upgrades directly from the Internet
Specifications
- Display: 178 mm (7 in) diagonal color TFT, capacitive touch sensing
- Inputs
- Total 22
- Mic/Line 16 (12 XLR, 4 XLR combo)
- Line 2 Stereo (1/4" TRS)
- Stereo USB Stereo USB / MP3 playback
- Talkback 1 (XLR)
- Input Channel Processing
- EQ 4-band Parametric EQ with Hi/Low Shelving option, variable 24 db/octave HPF and LPF
- Dynamics Gate, Compressor
- Delay Delay (100 msec max)
- Automatic Microphone Mixer N/A
- Outputs
- Total 12
- Main L/R 2 (XLR, line-level)
- Aux 6 (XLR, line-level) + 2 (TRS, stereo In Ear Monitor or mono balanced line-level)
- In-ear Monitor (Stereo) 2 (TRS, 16 ohm min. impedance, from Auxes 7/8 and 9/10)
- Cue 1 (Stereo, TRS, line or headphone, 16 ohm min. impedance)
- Monitor L/R 1 (Stereo, TRS, line or headphone, 16 ohm min. impedance)
- Output Channel Processing
- EQ 1/3 octave GEQ, 6-band Parametric EQ, Variable High- and Low-Pass Filters
- Anti-Feedback Filters 8-band Anti-Feedback Filters
- Dynamics Limiter
- Delay 100 msec
- Recording / Playback1
- Multi-Track 22 × 22 tracks direct to hard drive
- DAW N/A
- MP3 Stereo USB / MP3 playback
- Groups
- DCA 8 (with Mutes)
- Mutes 8
- Sub Groups N/A
- Cue: Selectable. AFL, PFL
- Effects
- 4 simultaneous, professional effects engines including Reverb, Echo, Delay, Chorus, Pitch Shift
- 1 Pitch Correct (assignable to any mono input channel)
- Real Time Analyzer (RTA)
- 1 (1/3 octave. Assignable to channels or user selectable source)
- Preset Memory: 99 User Scenes, 120 Factory Presets, 99 User Presets
- Digital Connections: 2 USB A connectors
- External Control2
- TouchMix-8/16 Control App for iOS® and Android devices controls all mixer functions via Wi-Fi.
- Wi-Fi3
- USB Wi-Fi adaptor (included) or external Wi-Fi router (requires USB to ethernet adaptor)
- Dimensions (H×W×D)
- Shipping Container
- 620 × 380 × 120 mm
- 24.4 × 15 × 4.7 in
- Mixer only
- 58 × 360 × 291 mm
- 2.3 in × 14.2 in × 11.5 in
- Weight
- Shipping 5.2 kg / 11.5 lb
- Mixer only 2.98 kg / 5.9 lb
- Power Requirements: 42 W, 100 - 240 VAC, 50 - 60 Hz
- Sampling Frequency: Selectable 44.1 kHz or 48 kHz
- Internal Processing: 32-bit floating point
- THD: <0.005%, +4 dBu; 20 Hz-20 kHz, unity gain, any input to any output
- Frequency Response: 20 Hz-20 kHz +/-0.5 dB, any input to any output
- Dynamic Range: 105 dB
- Equivalent input Noise: -126 dBu
- Residual Output Noise: -86 dBu
- Crosstalk: -80 dB
- S/N Ratio: -94 dB
- Gain (Mic Inputs): 75 dB (60 dB analog, 15 dB digital)
- Maximum input Level
- +16 dBu (Mic/Line inputs, XLR), +26 dBu (Mic/Line inputs, TRS), +22 dBu (Stereo inputs)
- Maximum Output Level: +22 dBu (all line-level outputs)
- Phantom Power: 48 v, all mic inputs, individually switchable
- Included Accessories: USB Wi-Fi adapter, soft carrying case, power supply
Outputs | |
Total | 12 |
Main L/R | 2 (XLR, line-level) |
Aux | 6 (XLR, line-level) + 2 (TRS, stereo In Ear Monitor or mono balanced line-level) |
In-ear Monitor (Stereo) | 2 (TRS, 16 ohm min. impedance, from Auxes 7/8 and 9/10) |
Cue | 1 (Stereo, TRS, line or headphone, 16 ohm min. impedance) |
Monitor L/R | 1 (Stereo, TRS, line or headphone, 16 ohm min. impedance) |
Output Channel Processing | |
EQ | 1/3 octave GEQ, 6-band Parametric EQ, Variable High- and Low-Pass Filters |
Anti-Feedback Filters | 8-band Anti-Feedback Filters |
Dynamics | Limiter |
Delay | 100 msec |
Recording / Playback1 | |
Multi-Track | 22 × 22 tracks direct to hard drive |
DAW | N/A |
MP3 | Stereo USB / MP3 playback |
Groups | |
DCA | 8 (with Mutes) |
Mutes | 8 |
Sub Groups | N/A |
Cue | |
Selectable. AFL, PFL | |
Effects | |
4 simultaneous, professional effects engines including Reverb, Echo, Delay, Chorus, Pitch Shift | |
1 Pitch Correct (assignable to any mono input channel) | |
Real Time Analyzer (RTA) | |
1 (1/3 octave. Assignable to channels or user selectable source) | |
Preset Memory | |
99 User Scenes, 120 Factory Presets, 99 User Presets | |
Digital Connections | |
2 USB A connectors | |
External Control2 | |
TouchMix-8/16 Control App for iOS® and Android devices controls all mixer functions via Wi-Fi. | |
Wi-Fi3 | |
USB Wi-Fi adaptor (included) or external Wi-Fi router (requires USB to ethernet adaptor) | |
Dimensions (H×W×D) | |
Shipping Container | 620 × 380 × 120 mm |
24.4 × 15 × 4.7 in | |
Mixer only | 58 × 360 × 291 mm |
2.3 in × 14.2 in × 11.5 in | |
