The Trace Elliot® ELF® 1x8 Combo Bass Amplifier redefines what you can expect from a mini bass amp by incorporating the finest speaker components to produce a robust, larger-than-life tone.

This ultra-portable mini combo amp can be carried effortlessly in one hand and combines exceptional sound quality and unmatched convenience. Whether performing on stage or practicing at home, the ELF 1x8 Combo Bass Amplifier sets a new mini amp standard for bassists everywhere.

Small Amp, Big Tone

If you are looking for a mini bass amp that manages to replicate the rich, full sound of its larger counterpart then Trace Elliot has you covered! The Trace Elliot® ELF® 1x8 Combo is known for punching well above its weight. At only 17 pounds, the ELF 1x8 mini bass amp is purpose-built to replicate the sound of its larger counterparts in a smaller package. Amplify your tone with the uncompromising sound and quality of the ELF 1x8 combo bass amplifier.

The Magic of ELF

With the legendary, ultra-compact ELF bass amplifier built-in, the Trace Elliot ELF 1x8 Combo is gig-ready right out of the box. Play loud and proud with a fan-cooled 200 Watts RMS into 4 ohms. Are you playing in a larger venue? No problem. Connect the crystal-clean, post-EQ DI to the front-of-house feed to optimize your tone to the size of the room. The ELF 1x8 is ready for any gig that comes your way.

Ready for the Road, Ready to Record

When you're on the road, the ELF 1x8 mini bass amp demonstrates incredible flexibility, effortlessly adapting to various performance demands. This small and unexpectedly loud amp ensures your sound remains consistent and powerful, making it a reliable companion for any gig.

At home and in the studio, the ELF 1x8 maintains its impressive flexibility. The balanced XLR DI output with ground lift sends classic Trace Elliott tone to any mixing console or recording device. A 1/4" headphone output allows for quiet practice without bothering your neighbors.

• Ultra-portable at only 17 pounds
• 200 Watts into 4 ohms, 130 Watts into 8 ohms
• 3-band rotary EQ
• Post EQ balanced XLR DI output with ground lift
• 1/4" headphone out, external speaker out

Experience an amp that is both powerful beyond its size and incredibly versatile. The Trace Elliot ELF 1x8 Combo Bass Amplifier's compact design makes it easy to hit the road and deliver your best performance.

• Mains Voltage: 100-120 vac - 50/60Hz - T3.15AL/250V
  230 vac - 50/60Hz - T1.6AL/250V
• Power Consumption: Typical = 30W
  Maximum = 240W
• SMPS: Thermal protection
  Over-current protection
• Power Amplifier Protection: Clip limiting
  Thermal
  Over-current / Short-circuit
  DC output
• Minimum Load: 4 Ω
  example--
  1 - 4 Ω cabinet / 2 - 8 Ω cabinets
• Power Output (1% THD): 130W - 8 Ω - Internal 8 ohm speaker
  200W - 4 Ω - With external 8 ohm cab
• Noise: -62.5 dBu
• Pre Amp Nominal Input Sensitivity: All controls @12:00 = -6.44dBu (369mV)
• Input Impedance: >10 meg Ω
• EQ: 3 - band rotary type with proprietary TE filters
  Low center = 80 Hz
  Mid center = 400 Hz
  High center = 4.2 KHz
• DI XLR Balanced Output: PIN 1 = GND, PIN 2 = sig+, PIN 3 = sigPost EQ
  1 KΩ output impedance w/GND lift switch, noise floor = -104.3dBu, noise floor w/sig (nom.) = -88dBu
