EVE E-50Z is a compact ellipsoidal luminaire that projects clear patterns of warm white light, with D-Fi ™ compatibility for wireless control in master/slave mode or by DMX. The manual adjustment of zoom and the cutters, facilitate the control and modeling of the projected light beam at any distance. The EVE E-50Z includes support for metallic or glass gobos, and color filters, and can operate autonomously without the need for DMX controllers. By connecting the power of several units in a chain, you save time and extensions in your installation.

Highlights

• LED Ellipsoidal shines a hard-edged, warm white spot in any direction
• Easily highlight areas by altering the projected beam with framing shutters
• Flexibility to project from any distance using the manual zoom
• D-Fi USB compatibility for wireless Master/Slave or DMX control
• Flicker-free operation suitable for on-camera use
• Includes holders for glass and steel gobos and a gel frame
• Save time running extension cords by power linking multiple units
• Eliminate the need for DMX control with a standalone operation
• Available in black or white

• DMX Channels:1 or 3
• DMX Connectors:3-pin XLR
• Light Source:1 LED (warm white) 50 W, (1.3 A), 50,000 hours life expectancy
• Strobe Rate:0 to 29 Hz
• PWM Frequency:2 kHz
• Illuminance:(20°): 7,910 lux @ 2 m
  (39°): 2,710 lux @ 2 m
  (20°): 1,479 lux @ 5 m
  (39°): 508 lux @ 5 m
• Power Linking:16 units @ 120 V; 26 units @ 230 V
• Input Voltage:100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current:59 W, 0.5 A @ 120 V, 60 Hz
  63 W, 0.3 A @ 230 V, 50 Hz
• Gobo Size:D (53.3 mm outside, 43 mm image, 2mm max thickness)
• Zoom Angle:(manual): 20° to 39
• Weight:2 lb (4.2 kg)
• Size:9 x 6.2 x 15 in (480 x 157 x 381 mm)
• Approvals:CE, MET
• Color Temperature:3500 K
• Gel Frame Size:5 in (140 mm)
• Optional Controllers:D-Fi USB
• CRI:8
• Support for glass or metal gobos
• Hanging bracket with mounting
• Power cord
• Harness with mounting accessories
• Warranty
• Quick Reference Guide
